PA Refernce 2XS

Product Name

  • Model :PA Refernce 2XS
  • Brand :ground
  • Specificity :독일 그라운드 제로 하이엔드앰프
    A클래스 앰프로 음질 최상 - 2채널

Product description

독일 그라운드 제로의 하이엔드 앰프입니다.
A클래스 앰프로 SQ용으로 많은 음색과 정보량은 어느제품에도 뒤지지 않는 모델입니다.
앰프의 끝으로 봐도 되는 제품으로 A클래스 앰프만의 쏟아지는 정보량과 높은 해상력을 느끼실 수 있습니다.

Specifications
RMS Power @ 4Ω, 1% THD / 10% THD
CEA Standard CEA-2006-A
2 x 200W / 2 x 250W
RMS Power @ 2Ω, 1% THD / 10% THD
CEA Standard CEA-2006-A
2 x 380W / 2 x 450W
RMS Power @ 4Ω Gebruckt, 1% THD / 10% THD
CEA Standard CEA-2006-A
1 x 760W / 1 x 900W
Dampfungsfaktor / Damping factor / Damping Facteur
> 250
Tiefpass Weiche / Lowpass crossover / Filtre passe bas reglables
40Hz ~ 3000Hz
Hochpass Weiche / Highpass crossover / Filtre passe haut reglables
40Hz ~ 3000Hz
Bandpassfilter / Filtre passe-bande
40Hz ~ 3000Hz
Phaseshift
0 ~ 180˚
BIAS
Class A > Class AB
Frequenzgang / Frequency response / Frequence
10Hz ~ 30KHz
Wirkungsgrad / Efficiency / Effcaciter @ 4Ω
80%
Betriebsspannung / Operating voltage / Tension d’ emploi
11 ~ 15 V DC
Eingangsempfindlichkeit / Input sensitivity / Sensibilite d’ entrer
100 mV ~ 10 V (± 5%)
Sicherung / Fuse / Fusible
3 x 40A
Abmessungen / Dimensions B x H x L mm
236 x 67.5 x 420
Abmessungen / Dimensions B x H x L mm
9.29” x 2.66” x 16.54”
Features
High End Audio-transistors, Elna and Mundorf MCap® copacitors
Burr Brown IC’s for outstanding sound quality
Powerful shielded dual power supply, with extremely less interference
Variable bias setting to adjust the bias from normal class AB to nearly class A operation
The smoked plexiglas bottom with white LED illumination allowas to see the impressive PCB
Technical data
Type
2ch Class AB > A
Output power @ 4 ohem (CEA*)
2 x 200W
Output power @ 2 ohem (CEA*)
2 x 380W
Output power @ 1 ohem (CEA*)
-
Bridge mode @ 4 ohm (CEA* / 10% THD)
1 x 900W
Bridge mode @ 2 ohm (CEA* / 10% THD)
-
Output power linkmode 2 ohm
-
24 Volt Unit
-
18 Volt stable
-
Lowpass
40 ~ 3000Hz
Highpass
40 ~ 3000Hz
Bandpass
40 ~ 3000Hz
Subsonic
-
Bassboost
0 ~ 12dB
Phaseshift
0 ~ 180˚
Adjustable Q-factor
-
Variable Bias Setting
Ja / Yes
Bass remote
Ja / Yes
High Level in
-
Line Out
-
Illumination
Weifle LED Innenbeleuchtung / white LED illumination
Dimensions cm / lnch
42 x 6.75 x 23.6 cm / 16.5” x 2.66” x 9.29”
